main performance parameters of 928 loader
| Performance | 1 | rated loading | 2000kg |
| 2 | overall weight | 5000kg | |
| 3 | rated bucket capacity | 1.0m3 | |
| 4 | maximum tractive force | ≥58KN | |
| 5 | maximum breakout force | ≥55KN | |
| 6 | maximum grade ability | 30℃ | |
| 7 | maximum dump height | 3100mm | |
| 8 | maximum dump reach | 780mm | |
| 9 | overall dimension (L×W×H) | 6200*2300*2900mm | |
| 10 | minimum turning radius | 4750mm | |
| Engine | 11 | model | 4108 |
| 12 | type | lnline water cooled, four stroke | |
| 14 | rated power | 76kw | |
| 15 | maximum torque | 500N.m | |
|
Transmission system |
17 | torque converter | ZL280 |
| 18 | gearbox mode | Countershaft power-shift | |
| 19 | gear shift | 2 forward shift 2 reverse shift | |
| 20 | maximum speed | 28km/h | |
| Drive axles | 21 | main reducing mode | Circular Arc Bevel gear, single stage |
| 22 | decelerating mode | Single stage planetary type | |
| 23 | wheel base (mm) | 2400mm | |
| 24 | wheel tread | 1680mm | |
| 25 | ground clearance | 310mm | |
|
Hydraulic system |
26 | system working pressure | 16MPa |
| 27 | boom lifting time | 4.8s±0.2s | |
| 28 | total time | 9.2s±0.5s | |
| 29 | fuel tank capacity | 80L | |
| 30 |
function of leveling automatically |
yes | |
|
Brake system |
31 | service brake | air assist disc brake on 4 wheels |
| 32 | parking brake | flexible shaft operated external drum | |
|
Tyre |
33 | type specification | 16/70—20 |
