Categories: WHEEL LOADER
Main performance parameters of BENS TRUCK 968 WHEEL loader
| Performance | 1 | rated load | 6000KG | |
| 2 | overall weight | 19800KG | ||
| 3 | rated bucket capacity | 3.3m3 | ||
| 3 | maximum tractive force | 158KN | ||
| 4 | maximum breakout force | 204KN | ||
| 5 | overall dimension (L×W×H) | 8250×3100×3400mm | ||
| 6 | maximum grade ability | 30℃ | ||
| 7 | maximum dump height | 3350mm | ||
| 8 | maximum dump reach | 1255mm | ||
| 9 | minimum turning radius | 6500mm | ||
| Engine | 11 | model | Weichai Steyr WD10G240E21 | |
| 12 | type | lnline water cooling dry cylinder injection | ||
| 13 | -×No. of cylinder-bore/stroke | 6－126×130mm | ||
| 14 | rated power | 175kw–2200r/min | ||
| 15 | maximum torque | 843N.m | ||
| 16 | min fuel-consume ratio | ≤220g/kw.h | ||
|
Transmission system |
17 | torque converter | ＹＪ375 | |
| 18 | gearbox mode | Power shift normally engaged straight gear | ||
| 19 | gear shift | 4forward shift | 4 reverse shift | |
| 20 | maximum speed | 38km/h | ||
| Drive axles | 21 | main reducing spiral | bevel gear grade 1reduction | |
| 22 | decelerating mode | planetary reduction,grade 1 | ||
| 23 | wheel base (mm) | 3350mm | ||
| 24 | wheel tread | 2250mm | ||
| 25 | minimum ground clearance | 450mm | ||
|
Hydraulic system |
26 | system working pressure | 18MPa | |
| 27 | boom lifting time | 6.15+0.25s | ||
| 28 | total time | 10.65+0.5s | ||
| 29 | fuel tank capacity | 300L | ||
| 30 | function of leveling automatically | yes | ||
|
Brake system |
31 | service brake | air over hydraulic disc brake on 4 wheels | |
| 32 | parking brake | manual parking brake | ||
|
Tyre |
33 | type specification | 26.5-25 | |
| 34 | front tyre pressure | 0.4Mpa | ||
| 35 | rear tyre pressure | 0.35Mpa | ||
